- 7310A
- Model number 7310A
Description Angular rate 2V full scale Rugged
Range deg/sec ±100/±500/±1500/±6000/±8000/±12,000/±18,000
Sensitivity mV/g/sec +/-15% 20/4/1.333/0.333/0.25/0.167/0.111
Frequency response Hz +1/-3dB 0-1000(100/500)/0-2000
Non linearity % FSO 0.5
Shock limit g 5000
Operating temperature℃(℉) -40 to +105 (-40 to +221)
Dimensions mm (in) 14.6 x 10.2 x 7.62 (0.580 x 0.400 x 0.300)
Weight grams 3
Rate excitation voltage Vdc 5 to 16
Mounting method 0-80 screws
- 7360A
- Model number 7360A
Description 6DoF measurement Compact package with 2 cables Rugged fo 5000 g shocks
Accelerometer ranges g ±2/±10/±50/±200/±500
Range deg/sec ±100/±500/±1500/±6000/±8000/±12,000/±18,000
Accelerometer sensitivity mV/g typical 1000/200/40/10/4
Sensitivity mV/g/sec +/-15% 20/4/1.333/0.25/0.167/0.111
Acceleroemter frequency response +/-1dB 0-300/0-1500/0-1800/0-1800/0-1800
Frequency response Hz+1/-3dB 0-1000/0-1000/0-1000/0-1000/0-2000/0-2000
Non linearity %FSO 0.5
Shock limit g 5000
Operating temperature℃(℉) -40 to +100 (-40 to +212)
Dimensions mm (in) 30.5 x 30.5 x 27.9 (1.2 x 1.2 x 1.1)
Weight grams 35
Accelerometer excitation voltage Vdc 7 to 36 or 5V (M1 option)
Rate excitation voltage Vdc 5 to 16
Mounting method 4-40 screws
